9-52 Structure and Assembly/Disassembly

No.

Device Name

Port

Description

5. Motion (abdomen) sensor support: stick the sensor

support against the top left of the patient’s

abdomen with the medical plasters (below left

costal arch, right above the navel, the area where

the skin moves apparently with the respiration).

<9>

Magnetic

navigator

Place the magnetic navigator behind the Ultrasound

System. Power on the navigator to enable the

positioning function.

Face downward
