System Preparation 3-13
None-fixing Area
Position of areas illustrated here are not fixed, you can move them by the trackball within
a certain area on the display.
Result window
The measurement result window displays the results of recently performed
measurements.
To move the result window:
a) Place the cursor on the title of result window (you can see the cursor changes
into
).
b) Press <Set> and move the trackball, the window moves together with the cursor.
c) Move the cursor to the target position, press [Set] again to anchor the result
window in the target position.
Comment area
For details, please refer to “8 Comments and Body Marks”.
Body mark area
For details, please refer to “8 Comments and Body Marks”.
3.11.2 Basic Operations of Screens
A screen consists of title, page tabs, contents and buttons, as shown in the following figure:
Title Bar
The title bar is used to give a description for the content and
function of the screen.
Page Tab
For some screens, contents are distributed across several
pages. Use the selection pointer and <Set> key to
open/close the available pages. Use the selection pointer
and [Set] key to open / close the available pages.
