Part I Service Scenarios
Installation 28
Item Description
Add Service Click Add Service to add a print service.
Remove Service Select a service and click Remove Service to delete the selected service.
Rename Service Rename a selected service.
Default Print Service Click Default Print Service to set the selected print service as the default one.
PROPERTY Set service properties such as Service Type and Paper Size. The configuration
varies according to the print service type. Available print service types include
Report Print and Digital Image Print.
1.2.6.10 Setting the Footswitch
1. After the ultrasound system is started, select Setup on the touch screen to access the setup screen.
2. On the setup screen, choose System > Key Config. In the Key area, select Footswitch.
3. Select the desired key in the Key Function column on the left of the page.
4. Click to select a function in Function area. The selected function is displayed on the right of the
selected key.
5. Click Save.
1.2.6.11 Setting the Barcode Scanner
1. After the ultrasound system is started, select Setup on the touch screen to access the setup screen.
2. On the setup screen, choose System > Barcode.
3. Select the corresponding tab and set related options.
˗ 1D Barcode Scanner
Setup items are described as follows:
