Mindray MX7 Service Manual

Part I Service Scenarios
Maintenance 45
2.1.3 Daily Maintenance
Figure 2-1 Cleaning flow
Clean dust-proof mesh
Clean the monitor
Clean the trackball
Clean the holder
Clean the cover
Clean the probe
Clean the control panel
Shut down the system; unplug
power supply cable
WARNING:
Before cleaning the system, be sure to power down the system and remove the
power cable. If you clean the system in the power-up state, an electric shock may
be caused.
2.1.3.1 Cleaning the Dust Filters
Dust filters of the main unit
 Tool: soft brush
 Method:
Take off the dust filters on the side of the main unit.

Mindray MX7 Specifications

General

Display Size	15.6 inches
Transducer Ports	3
Portability	Portable
Type	Ultrasound System
Display Type	LCD
Battery Life	120 min
Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler
Connectivity	Wi-Fi, Ethernet, USB
Applications	Vascular, Cardiology, OB/GYN, Urology
Probe Connectors	3
Operating System	Windows
