Mindray Zonare ZS3 User Manual

ZS3 Instructions for Use
106 | P a g e
Soft Keys (OLED)
Stage Available Softkey (OLED) Controls Available Onscreen Controls
Acquire
End acquisition
Suspend SE. If SE is
suspended, pressing
Protocol key or
programmable key
assigned to SE will re-
enter exam
Reference Image On/Off
End SE
Text On/Off
Playback Speed +/-
Delete Unselected
Acquisition pause
Exam timer on/off
Stage timer on/off
Mode
Stages
Views
Resting images
available for
selection
Post images available for
selection
End Acquisition
Select
End SE
Suspend SE. If SE is
suspended, pressing
Protocol key or
programmable key
assigned to SE will re-
enter exam
Bookmark
First Page/Last Page
Page X/X
Mode
Stages
Views
Delete Unselected
Text On/Off
Playback Speed +/-
Mode
Suspend exam: If SE
is suspended,
pressing
programmable key
assigned to SE will
re-enter exam
End SE exam
Stage and available
views to choose from
Navigation arrows for
available images and
pages
Stage of protocol is
duplicated onscreen for
easy access.
Review/
WMS
Current Normal
All Normal
Prev Page/ Next Page
First/Last
Compare Mode On/Off
(Stage, View, Shuffle)
End SE
Suspend SE. If SE is
suspended, pressing
Protocol key or
programmable key
assigned to SE will re-
enter exam
WMS model
16 or 17 segment
Scoring 4, 5, or 7 Mode
Mode
Stage
Views
Text On/Off
Delete Unselected
Cine playback
Cine navigation
controls
Text on/off
Review mode
Stages and views
Suspend exam: If SE is
suspended, pressing
programmable key
assigned to SE will re-
enter exam
End SE exam
Wall Motion Scoring
Stage of protocol is
duplicated onscreen for
easy access.
Stress Echo protocols can be customized using the Setup/ Stress Echo tab.
