1. Enter the required FTP configuration values in the fields of Service Name/IP
Address/Port/User Name/Password. Parameters specified in the above figure are
given as an example.
2. Select [Active] of the Data Transfer Mode.
3. Click [Add], and the FTP Service is displayed in the Service list.
4. Click [Ping]. Until successful ping, the message "Connection succeeded!" is
displayed.
5. Click [Update] to update modified configuration values, and click [Delete] to delete
the selected FTP Service.
6. Click [Save] to exit.
QPath/QView
You can use the ultrasound system to check data on browser directly. After you have
ordered storage service of a network website service, you can check data using the
website, authorized account and password (provided by the service vendor).You can
open the browser to review previously sent DICOM data.
1. Enters [Setup] [Network] [QPath/QView].
