Mindray Zonare ZS3

ZS3 Service Manual
Page 126 of 295
12 Functional Descriptions
System Capabilities
 64-hardware - 128/192-synthetic channel system
 Supports B-Mode, M-Mode, Color, Power Doppler, PW, ARFI
 19” full-screen, 1280 x 1024 resolution, Display
 Full-sized alpha-numeric user keyboard
 Discrete function user controls
 Software mode assignable user controls
 User programmable keys
 Integrated stereo speakers (located in display)
 External I/O device connectivity
o Ethernet 10/100Base-T
o eSata/USB Connector
o USB port
o HDMI Connector
 Internal solid-state drive (image archive)
 On-board Z-Pack Battery Module (Option)
Major FRUs
MODULE
 P/N 115-058353-00 ZS3 Module Kit(ARFI,Without ECG/9.x)
 P/N 115-058354-00 ZS3 Module Kit(ARFI,Aux-ECG/9.x)
Figure 12.1-ZS3
DOCK BOARD WITH CART SSD&CHASIS, P/N: 115-029533-00
 115-029534-00 Dock Board(FRU)
 115-029548-00 SSD Assembly(FRU)
