ZS3 Instructions for Use
54 | P a g e
Probe Length(mm) Width(mm) Height(mm) Cable Length(mm)
P8-3TEE 1100 14.2 11.5 1750±50
P8-3m TEE 720 10.9 8.7 1830±50
L30-8 30 18.2 15 2025±50
P7-3c 80 33.4 26.5 1980±50
C12-4lp 560 66.5 50 2525±50
The above is a dimension illustration of the L14-5w probe.
You can select the probe sheath according to the actual application situation.
