Mindray Zonare ZS3

ZS3 Service Manual
Page 44 of 295
Rear I/O Panel
Figure 4.6-ZS3: Rear I/O Panel
FUNCTIONS: I/O CONNECTORS
# Function Direction
1 Ethernet 10/100BaseT - (Network) Input/Output
2 Serial Port - eSATAp Input/Output
3 USB Port Input/Output
4 HDMI Connector (video and audio) Input/Output
