Figure 2.7: Full Image Onscreen Display
Patient and Institution Information
Includes Manufacturer Logo and Institution Name: Configured in Setup/System/General.
Includes Patient Name, ID, Gender, and Age: Information entered on the Patient ID page. Also
displays: Probe/Preset as selected with transducer, exam type, exam date/time, and
Operator
Menus Includes annotation lists, measurement options, calculations menus, stress echo
navigation, and protocol information.
Trackball and set keys are used to navigate this area.
Image Area
Displays the ultrasound images, Doppler spectral strip, M Mode strip, image depth markers, ECG
and respirometer waveforms, probe indicator, and calculations/measurement results window.
Image Parameters
Displays the image parameter for the active window. If there is more than one imaging mode
active, the parameters are displayed for each mode.
Trackball-Priority ICON
Displays:
• 2 Set Keys with labels indicating active state of keys
• 1 Select Key with labeling indicating active state of key
• 1 Pointer Key labeled
• Trackball with center graphic indicating active state of trackball
