Mindray Zonare ZS3

ZS3 Service Manual
Page 28 of 295
No
Transducer
Parameter
1.
C10-3
 Penetration Depth: 13 14 CM
 Number of Elements: 64
 Field of View: 80 degrees
 Radius of Curvature: 16 mm
 Ultrasound Bandwidth: 10-3 MHz
2.
C9-3
 Penetration Depth: 18 CM
 Number of Elements: 128
 Field of View: 67 degrees
 Radius of Curvature: 33 mm
 Ultrasound Bandwidth: 9-3 MHz
3.
C9-3sp
 Penetration Depth: 18 CM
 Number of Elements: 128
 Field of View: 67 degrees
 Radius of Curvature: 33 mm
 Ultrasound Bandwidth: 9-3 MHz
4.
C6-2
 Penetration Depth: 24 CM
 Number of Elements: 128
 Field of View: 65 degrees
 Radius of Curvature: 50 mm
 Ultrasound Bandwidth: 6-2 MHz
5.
C4-1
 Penetration Depth: 30 40 CM
 Number of Elements: 64
 Field of View: 80 degrees
 Ultrasound Bandwidth: 4-1 MHz
