Play/Pause When the image is frozen, this control provides a means to toggle between playing
and pausing the contents of the Cine Buffer.
When Paused, the same dial navigates frame by frame.
When the image is playing, this control increases and/or decreases the playback
speed.
Trim Provides easy access to the Trim Function.
Press this OLED and then use the Left and Right Set keys to establish the
beginning and ending points of the desired clip.
Acoustic Power When entering CEUS, this control allows user to adjust the Mechanical Index (MI)
to ensure contrast bubbles are preserved or disrupted as necessary.
Sequence Select
Use this OLED to select which
predefined Sequence will be started after the Sequence
Sequence
Start/Pause/Resume
During a sequence, the system automatically adjusts multiple parameters including but
not limited to number of steps, duration of steps, MI during the step, Frequency used
g a step and Frame Rate applied, and stores the Sequence
hen completed.
Press Up on this toggle to Start a Sequence.
System automatically ends the Sequence when the predetermined steps have been
Completed.
Press Up on the toggle again before the Sequence has been completed, and the
Sequence will pause.
While the Sequence is paused, pressing Up again on the toggle resumes the
Sequence.
Press Down on the toggle at any time during the Sequence, and the Sequence will be
ended.
Peak Hold
Accessed via the Clip A/Peak
Hold/Clip B OLED
When selected, pressing the configured Store or Print key shall acquire a Peak Hold clip.
L/R or R/L Image Swap
Press this control to switch the display between CEUS image on left and reference image
on right to CEUS image on right to
reference image on the left
Frequency
While CEUS Is active, pressing the Frequency button will change the frequency of the
CEUS image.
