FTP Configure an FTP destination including IP Address, password, port, and data transfer mode.
QPath/
Q-View
Configure (import, backup, restore, and delete) QPath worksheet linkages and passwords
Configure Q-View, which is a client viewing tool for the server.
The primary purpose of Q-View is to provide remote access to Q-Path from the ultrasound
system, thereby, allowing the users to complete the exam report on the ultrasound system
and submit.
VPN
Configure a Virtual Private Network (VPN) connection including Server IP, Group, User Name
and Password to allow for encrypted transfer.
Keys Description of Control
Programmable
Keys
Configure exam category (Cardiac, Abdominal, Obstetrics, Gynecology, Vascular,
Pediatrics, Urology, POC, and Small Parts) specific programmable keys including Function
keys, and Footswitches.
Selections are also available to configure the B Mode Knob (B Mode or B Mode Home)
and trackball speed which are not category specific.
Image Store /
Print Buttons
Configure capture type (cine/still, image/screenshot), storage destination of Store 1, Store 2,
and Print Keys, Reports, and transfer type (exam in progress or end exam).
Store Configure compression level/quality for image storage.
Select clip configuration assignment (All Presets or Preset Specific)
Peripherals Description of Control
Print Service Setup a local printer.
Barcode Reader
Configuration
Configure a barcode reader including fields to match, worklist options, and barcode reader
device assignment.
Power Save Configure sleep and shutdown behavior when on battery and external power.
Backup / Restore Description of Control
Backup/Restore To initiate a Backup or Restore of Presets and System data to and from a USB device.
To restore factory defaults of Preset and System files.
