ZS3 Instructions for Use
42 | P a g e
Needle-guided Bracket
Needle-guided brackets are available for purchase as optional accessories and are used in
combination with the probe. Some probes have corresponding needle-guided brackets and
needles. To order needle-guided brackets, contact the MINDRAY Customer Service Department or
a sales representative.
For biopsy or treatment, ultrasound-guided biopsy procedures can be performed using the probe
together with a needle-guided bracket (optional accessory) and a biopsy needle (provided by the
user).
Some of the probes have corresponding needle-guided brackets for biopsy. The available probes
and the corresponding needle-guided brackets are listed as follows:
Transducer
Needle-guided
Bracket
Biopsy angle/depth
(±1°)
Applicable Biopsy
Needle
C6-1
NGB-022
metal/needle
detachable
25°, 35°, 45°
14G, 16G, 18G, 20G, 22G
CIVCO Bracket
Transducer
Needle-guided Bracket
C4-1
CIVCO 698-013; CIVCO 698-019
C6-2
CIVCO 698-003
C9-3
CIVCO 698-009
E9-3
CIVCO 698-002; CIVCO 698-014
E9-4
CIVCO 698-002; CIVCO 698-010
CIVCO 698-011; CIVCO 698-014
L8-3
CIVCO 698-005
L14-5sp
CIVCO 698-006
L14-5w
CIVCO 698-007; CIVCO 698-012
L10-5
CIVCO 698-004; CIVCO 698-008
CIVCO 698-015
Note: For details about the CIVCO needle-guided brackets, please refer to the accompanying
manual or directly contact the CIVCO for obtaining information.
Names of Parts
This section describes the parts and corresponding functions of each needle-guided bracket. Here,
we take a corresponding probe as an example.
