Page 10 The Minelab Eureka Gold
e) Firmly wind the cable up the stem using the Velcro
TM
tabs to hold in
position.
f) Connect the coil connector (13) to the plug (14) on the rear of the control
box.
d) Clip the control box onto the rear mounting bracket (see figure 5).
b) Slide in the black plastic rear control box bracket (8).
c) Tighten the nylon wing nut on the armrest.
3.6 Hipmounting/Chestmount
Hipmounting is an alternative to mounting the detector on the shaft and
significantly reduces physical strain, enabling longer search time without
undue fatigue. A hipmount bag is available as an accessory item
for this purpose.
a) Check that there are charged batteries in the control box.
b) Place the control box into the hipmount bag with its control panel
facing outwards (see figure 7).
c) Place the hipmount bag in your preferred
working configuration. The hipmount bag can
be worn on the belt or over the shoulder.
Note: If mounting the hipmount bag on the chest,
a belt can be thread through the belt loop and
around the chest to hold the bag in position.
d) Wind about 5 turns of the cable around the
shaft. This will reduce the amount of excess
cable.
Figure 7 - Hipmounting
the Control Box
P0582-A
