MINN KOTA FORTREX User Manual

minnkotamotors.com | 45
©2018 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
Assembly Part # Description Quantity
H 2417005 24V MOTOR 45” FW *80 LB* *24V* *45”* *4”* 1
J 2417006 MTR ASY 24V 4” VS FW 80 BS *24V* *4”* 1
K 2427005
Ì 24V MOTOR US2 45” *80 LB* *24V* *45”* *US2* *4”* 1
M 2427006 Ì 24V MOTOR US2 52” *80 LB* *24V* *52”* *US2* *4”* 1
U 2889460 SEAL & O-RING KIT *80 LB* *4”* 1
X 9421-244 Ì TRANSDUCER ASSEMBLY *52”* *80 LB* *4”* *US2* *NON MDI* 1
Z 9421-288 Ì TRANSDUCER ASSEMBLY *45”* *80 LB* *4.5”* *US2* *NON MDI* 1
AA 1378132 PROPELLER KIT WW2 *80 LB* 4” 1
SS 2437000
â MTR ASY 24V 4” 80# CB FW *80LB* *45”* *MDI* 1
TT 2437001 â MTR ASY 24V 4” 80# CB FW *80LB* *52”* *MDI* 1
V 2773007
â FORTREX 80-52" MDI TRANSDUCER *MDI* 1
W 2773001 â FORTREX 80-45" MDI TRANSDUCER *MDI* 1
Item Part # Description Quantity
2 2-100-214 ARMATURE ASSEMBLY *80 LB* 1
4 140-010 BEARING *80 LB* 1
6 788-040 RETAINING RING 1
8
2-200-160 CENTER HOUSING ASSEMBLY *80 LB* *4”* 1
2-200-130 CTR HSG ASY 4.0 CB FW MAG *80LB* 1
10 2-300-160 BRUSH END HSG ASY *80 LB* *4”* 1
12
✖ Ì
PLAIN END HOUSING ASSEMBLY STD *4”* *80 LB* *US2* • SEE X OR Z*
14 144-017 FLANGE BEARING 1
16 880-025 SEAL 2
18 725-095 PAPER TUBE - SEAL BORE 1
20 188-094 BRUSH *80 LB* 2
22 9-738-015 BRUSH PLATE ASSEMBLY *4”* 1
24 975-041 BRUSH SPRING *80 LB* 2
26 701-043 O-RING, MOTOR *80 LB* *4"* 2
28 701-009 O-RING, THRU-BOLT 2
30 830-027 SCREW, 10-32 X 2 *80 LB* 2
32 830-094 THRU-BOLT 12-24 2
34 990-051 WASHER, STEEL 1
36 990-052 WASHER, NYLATRON 1
38 973-025 SPACER, BRUSH PLATE *80 LB* 2
40 992-010 WASHER, BELLEVILLE *80 LB* 2
42 990-045 SPACER, THRUST *80 LB* 1
24 Volt 4” Motor Parts List
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
Ì Only available with models factory installed with Universal Sonar.
â Only available with models factory installed with Built-in MEGA Down Imaging.
p The Bow-Mount Stabilizer Assembly is not required or included on the 80lb
45” Fortrex.

MINN KOTA FORTREX Specifications

General

Thrust	80 lbs
Shaft Length	45 inches
Max Amp Draw	56 Amps
Speed Control	Variable
Blade Material	Composite
Motor Technology	Digital Maximizer
Voltage	24V
Control Type	Cable Steer Foot Pedal
Mount Type	Bow
Type	Trolling Motor
Battery Requirement	2 or 3 deep-cycle batteries
Warranty	2 years
