PARTS DIAGRAM & PARTS LIST
Item Part # Description Quantity
44 582-013 CLIP, RETAINING, SHORT, US2 ONLY *80 LB* 1
46
640-015 LEADWIRE, BLACK *80 LB* *45”* *4”* *US2* *NON US2* 1
640-016 LEADWIRE, BLK AWG 56 1/2 XLP *80LB* *45”* *MDI* 1
640-017 LEADWIRE, BLACK *80 LB* *52”* *4”* *US2* 1
48
640-119 LEADWIRE, RED *80 LB* *45”* *US2* *NON US2* 1
640-123 LEADWIRE, RED 10 AWG 64 XLP *4”* *52”* *80 LB* *US2* 1
640-121 LEADWIRE, RED *80 LB* *52”* *4”* *US2* 1
50
640-315 BONDING WIRE, BROWN 45” *45”* 1
640-316 BONDING WIRE, BROWN 52” *52”* 1
52
2032003 TUBE 45” 1
2032006 TUBE 52” 1
54 2331160 PROPELLER *80LB* *4”* 1
56 2262658 DRIVE PIN, LARGE 1
58 2091701 WASHER, PROP, LARGE 1
60 2093101 NUT, NYLOCK, PROP, LARGE 1
s
✖
TRANSDUCER ASSY 67” US2 W/T *45”* *SEE Z* 1
✖
TRANSDUCER ASSY 73” US2 W/T *52”* *SEE X* 1
62 2302104 SCREW - #6-20 X 3/8 THD CUTS, RI 1
s ✖
SCREW - #6-20 X 1/2 THD CUTS, RI 3
64 230-038
Ì CABLE CLAMP 1
66
✖
â
PLAIN END HOUSING US2 52” *80 LB* *4”* *MDI* *SEE V OR W* 1
68 230-039 â CABLE CLAMP, 1/4" STEEL 1
70 830-110
â SCREW-5-16-18 X 5/8 SHCS SS 2
72 792-001 â GUARD, TRANSDUCER, PNT 4.0 DI *80 LB* *4"* 1
74 421-276 HSG PLN END 4" PAINTED FW BS *80 LB* 1
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
Ì Only available with models factory installed with Universal Sonar.
â Only available with models factory installed with Built-in MEGA Down Imaging.
p The Bow-Mount Stabilizer Assembly is not required or included on the 80lb
45” Fortrex.
To Next Page
