48 | minnkotamotors.com
©2018 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
Assembly Part # Description Quantity
P 2317081 36V MOTOR 52” FW *112 LB* *36V* *52”* *4.5”* 1
Q 2327081
Ì 36V MOTOR US2 52” *112 LB* *36V* *US2* *52”* *4.5”* 1
R 2317080 Ì 36V MOTOR 45” *112 LB* *36V* *45”* *4.5”* 1
S 2327080 Ì 36V MOTOR US2 45” *112 LB* *36V* *US2* *45”* *4.5”* 1
T 2881450 SEAL & O-RING KIT *4.5”* *112 LB* 1
Y 9421-245
Ì TRANSDUCER ASSEMBLY *UP TO 52”* *112 LB* *4.5”* *US2* *NON MDI* 1
BB 1378160 PROPELLER KIT WW2 *112 LB* *4.5”* 1
XX 2437011
â MTR ASY 36V 4.5" 112# MDI FW *MDI* *52"* 1
YY 2437010 â MTR ASY 36V 4.5" 112# MDI FW *MDI* *45"* 1
VV 2773002 â FORTREX 112-52" MDI TRANSDUCER *MDI* *52"* 1
WW 2773008
â FORTREX 112-45" MDI TRANSDUCER *MDI* *45"* 1
Item Part # Description Quantity
80 2-100-245 ARMATURE ASSEMBLY *112 LB* 1
82 140-014 BEARING *112 LB* 1
84 788-040 RETAINING RING 1
86 2-200-240 CENTER HOUSING ASSEMBLY *4.5”* *112 LB* 1
88 2-300-155 BRUSH END HSG ASY 4.5” FW *4.5”* *112 LB* 1
90
✖ Ì
PLAIN END HOUSING ASSEMBLY STD *4.5”* *112 LB* *US2* *SEE Y* 1
92 144-017 FLANGE BEARING 1
94 880-025 SEAL 2
96 725-095 PAPER TUBE - SEAL BORE 1
98 188-095 BRUSH *112 LB* 2
100 9-738-015 BRUSH PLATE ASSEMBLY *4.5”* 1
102 975-045 BRUSH SPRING *112 LB* 2
104 701-098 O-RING, PLAIN END *4.5”* *112 LB* 1
106 701-103 O-RING, 103 MM X 3.00 MM, 70 BUNA *4.5”* 1
108 701-009 O-RING, THRU-BOLT 2
110 2053410 SCREW, 8-32 X 1/2 *112 LB* 2
112 830-094 THRU-BOLT 12-24 2
114 990-051 WASHER, STEEL 1
116 990-052 WASHER, NYLATRON 1
118 2307312 FERRITE BEAD 1
120 990-011 WASHER, SHIM 1
122 992-011 WASHER, BELLEVILLE *112 LB* 2
124 582-016 CLIP, RETAINING *112 LB* 1
36 Volt 4.5” Motor Parts List
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
Ì Only available with models factory installed with Universal Sonar.
â Only available with models factory installed with Built-in MEGA Down Imaging.
p The Bow-Mount Stabilizer Assembly is not required or included on the 80lb
45” Fortrex.
