PARTS DIAGRAM & PARTS LIST
Item Part # Description Quantity
126
640-040 LEADWIRE, BLACK 45” *112 LB* *4.5”* *45”* *US2* *NON US2* 1
640-043 LEADWIRE, BLACK 52” *112 LB* *52”* *4.5”* *US2* *NON US2* 1
128
640-140 LEADWIRE, RED 45” *112 LB* *4.5”* *45* *US2* *NON US2* 1
640-143 LEADWIRE, RED 52” *112 LB* *52”* *4.5”* *US2* *NON US2* 1
130
640-315 BONDING WIRE, BROWN 45” *45”* 1
640-316 BONDING WIRE, BROWN 52” *52”* 1
132
2032003 TUBE 45” 1
2032006 TUBE 52” 1
134 2341160 PROPELLER WW2 *112LB* *4.5”* 1
136 2262658 DRIVE PIN, LARGE 1
138 2091701 WASHER, PROP, LARGE 1
140 2093101 NUT, NYLOCK, PROP, LARGE 1
s
✖
TRANSDUCER ASSY US2 W/T *45”* 1
✖
TRANSDUCER ASSY US2 W/T *52”* 1
142 2302104
Ì SCREW - #6-20 X 3/8 THD CUTS, RI 1
s ✖
SCREW - #6-20 X 1/2 THD CUTS, RI 3
144 230-038 CABLE CLAMP 1
146
✖
â
PLAIN END HOUSING US2 52” *4.5”* *112 LB* *MDI* *SEE WW OR VV* 1
148 230-039 â CABLE CLAMP, 1/4" STEEL 1
150 830-110
â SCREW-5-16-18 X 5/8 SHCS SS 2
152 792-005 â GUARD, TRANSDUCER, PNT 4.5 DI *112 LB* *4.5"* 1
154 421-240 PLAIN END HSG 4.5" PNTD FW 4.5" LOWER UNIT *112 LB* 1
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
Ì Only available with models factory installed with Universal Sonar.
â Only available with models factory installed with Built-in MEGA Down Imaging.
p The Bow-Mount Stabilizer Assembly is not required or included on the 80lb
45” Fortrex.
