THIS ITEM IS PART OF AN ASSEMBLY.
*THIS ITEM IS PART OF A KIT AND ONLY LISTED FOR VIEWING PURPOSES.
ITEM QTY
PART
NUMBER
DESCRIPTION
735 1 2281702 WASHER, LOCK 1/4
737 1 2284212 OUTER ARM, LONG, 62”
740 1 2992302 ROPE GUIDE ASSEMBLY
745 1 2281530 INSERT, THREADED
750 1 2282608 PIN, 7/16 X 5 5/32
751 1 2282602 PIN, 3/8 X 3 3/4
752 2 2261505 SPACER
753 2 2263011 E-RING, 3/8 SHAFT
760 1 2223418 SCREW, 1/4-20 X 1/2 BHCS
765 1 2993821 INNER ARM ASSEMBLY, LONG, 62”
770 1 2042711 SPRING, TORSION
775 1 2283620 LATCH, SAFETY
776 1 2282611 SPRING, SAFETY LATCH
780 1 2281704 WASHER 7/16 NYLON
785 1 2280805 LINK, BOWGUARD MOUNT, RIGHT
790 2 2283410 SCREW 1/4-20 X 1/2 PFH
795 1 2288405 GAS SPRING, 112#, LONG
796 2 2281710 SPACER, GAS SPRING
800 1 2282610 PIN, UPPER, SHOCK
810 4 2280005 BEARING, NYLINER 7/16”
815 1 2282600 PIN, 7/16 X 4 7/8
820 2 2281932 BRACKET, REAR PIVOT
825 1 2281501 YOKE, SHOCK MOUNT
830 1 2282606 PIN, 7/16 X 4 1/2
835 2 2283402 SCREW, SET, 6-32 X 1/4
845 1 2282604 PIN, KNURLED 5/16 X 2
850 1 2283615 LATCH BAR
855 1 2283610 BRACKET - LATCH/STRAP, ROPE PULL
860 2 2287300 BUSHING, REAR PIVOT
865 1 2282602 PIN, 3/8 X 3 3/4
870 2 2263011 E-RING, 3/8 SHAFT
871 2 2280008 BEARING, IGLIDE
875 2 2282720 SPRING, EXTENSION
880 1 2773601 LATCH STRAP ASSEMBLY, LONG
885 2 2261732 WASHER 8, NYLON
890 2 2373450 SCREW 8-18 X 3/8
1 2993916 SIDEPLATE ASSY., LONG, LEFT, SW
895 1 2288625 SUPPORT, LEFT SIDEPLATE
900 8 2283408 SCREW 8 X 3/8
905 1 2283916 SIDEPLATE, LONG, LEFT, SW
910 2 2073408 SCREW 1/4-20 X 7/8
ITEM QTY
PART
NUMBER
DESCRIPTION
915 2 2286700 PLUG, SPACER
920 1 2283900 RAMP, MOTOR
1 2993926 SIDEPLATE ASSY., LONG, RIGHT, SW
925 1 2288620 SUPPORT, RIGHT SIDEPLATE
930 1 2283926 SIDEPLATE, LONG, RIGHT, SW
932 2 2285501 DECAL, SIDEPLATE, SW
935 1 2281912 BASE EXTRUSION, LONG, 62”
940 6 2323405 SCREW 1/4-20 X 1/2
975 1 2773806 STRAP HOLD DOWN
980 1 2991925 BRACKET STABILIZER ASSEMBLY
1 2265100 BUMPER (CRUTCH TIP)
1 2263624 ANODIZED ALUMINUM 3/4” ROD, 22”
1 2263107 HEX NUT 3/4-10 NYLON
1 2281929 STABILIZER ARM BRACKET
1 2260221 VINYL CAP
1 2223100 NYLOCK STAINLESS STEEL NUT
1 2263422 SCREW - 5/16-18 X 1”
1378160 PROPELLER KIT WW2 [1000-1020]
2994876 PROPELLER BAG ASSY [1010-1020]
1000 1 2341160 PROPELLER WW2
1010 1 2262658 DRIVE PIN, LARGE 1” X 3/16” SS
1015 1 2091701 WASHER, PROP, LARGE
1020 1 2198401 NUT, NYLOCK, PROP, ANODE
2994830 BAG ASSEMBLY
RIPTIDE FORTREX 112
112 LBS THRUST - 36 VOLT - 62” SHAFT
minnkotamotors.com | 21
©2015 Johnson Outdoors Marine Electronics, Inc.
PARTS LIST
