MINN KOTA Riptide User Manual

RIPTIDE FORTREX 112
112 LBS THRUST - 36 VOLT - 62” SHAFT
ITEM QTY
PART
NUMBER
DESCRIPTION
1 1 2317091 36V MOTOR 62” SW
5 1 2-100-245 ARMATURE ASSEMBLY
10 1 140-014 BEARING
15 1 788-040 RETAINING RING
20 1 2-200-340 CENTER HOUSING ASSEMBLY
25 1 2-300-151 BRUSH END HOUSING ASSEMBLY
30 1 421-241 PLAIN END HOUSING ASSY. STD
31 1 582-016 RETAINING CLIP
35 1 144-017 FLANGE BEARING
40 2 880-025 SEAL
41 1 725-095 PAPER TUBE - SEAL BORE
50 2 188-095 BRUSH
60 1 9-738-011 BRUSH PLATE ASSEMBLY
65 2 975-045 BRUSH SPRING
 2881450 SEAL AND O-RING KIT [40, 70-80]
70 1 701-098 O-RING, PLAIN END HOUSING
71 1 701-107 O-RING, BRUSH END HOUSING
80 2 701-009 O-RING, THRU-BOLT
85 2 2053410 SCREW-BRUSH PLATE
90 2 830-094 THRU-BOLT
95 1 990-051 WASHER, STEEL
100 2 990-052 WASHER, NYLATRON
110 1 2307312 FERRITE BEAD
115 1 990-011 WASHER, SHIM
120 2 992-011 WASHER, BELLEVILLE
135 1 640-045 LEADWIRE, BLACK 62”
136 1 640-145 LEADWIRE, RED 62”
200 1 2285605 DECAL, C-BOX COVER 112#
205 1 2060296 C-BOX COVER
208 2 2325666 DECAL - MINNKOTA
210 1 2074082 BATTERY METER, 36V SW
215 2 3043427 SCREW, #8 X 7/8 SS
220 1 2184017 CONTROL BOARD, 24/36V
 2888411 POTENTIOMETER REPLACEMENT KIT
225 2 2303434 SCREW, #8-30 X 5/8 SS
230 1 2062503 CONTROL BOX, VARS, SW
235 1 2062905 STRAIN RELIEF
240 6 2303412 SCREW, #6 X 5/8 SS
245 2 2263434 SCREW, #8 X 1 SS
250 1 2263406 SCREW, #10-24 X 2 SS
255 1 2061517 COLLAR, C-BOX
ITEM QTY
PART
NUMBER
DESCRIPTION
260 1 2333101 NUT, 10-24, NYLOCK, SS
265 1 2991521 CAM LOCK/DEPTH COLLAR ASSY
310 1 2002015 TUBE COMPOSITE 62”

1 2990957 HANDLE ASSY, VARS [360-410]
360 1 2990456 GRIP ASSY, VARS [360-375]
365 2 2060015 BEARING, HANDLE
370 1 2063405 SCREW, #6 PFH SS
375 1 2884092 YOKE / SPIDER ASSY, VARS
380 1 2302742 SPRING, DETENT, OFF
385 2 2060005 BEARING, HANDLE PIVOT
390 1 2060900 HANDLE PIVOT, TOP
395 1 2302745 SPRING, RELEASE BUTTON
400 1 2063700 BUTTON, RELEASE
405 1 2060905 HANDLE PIVOT, BOTTOM
410 6 2303412 SCREW, #6 X 5/8 SS
415 1 2062715 SPRING, HANDLE PIVOT
420 1 2061700 WASHER, POT HOLDER
425 1 2992521 LEADWIRE ASSY

1 2991757 BOWGUARD ASSY SW [500-570]
500 1 2283414 SCREW, 5/16-18 SHCS, RIE
510 1 2281700 WASHER, 5/16 HIGHCOLLAR LOCK
515 1 2281953 BOWGUARD TOP
520 1 2280001 BEARING, BOWGUARD TOP
525 1 2011366 KNOB, SS
530 1 2261525 SPRING SLEEVE, UPPER
535 1 2264702 TUBE INSERT, UPPER
540 1 2262705 SPRING, BOWGUARD
545 1 2282000 TUBE INSERT, LOWER
550 1 2281525 SPACER, LOWER SPRING
555 1 2281520 SPRING SLEEVE, LOWER
560 1 2991729 BOWGUARD BOTTOM
565 2 2282612 PIN-SPRING, 5/16”, SS
570 3 2283413 SCREW, 3/8-16 SHCS, RIE

1 2991751 MOUNT, FORTREX, 62” [700-940]
700 1 2280800 LINK, BOWGUARD MOUNT, LEFT
710 2 2287303 BUSHING, UPPER PINS
715 4 2283411 SCREW, 1/4-20 X 1” FHS RIE TORX
720 1 2880400 PULL GRIP ASSEMBLY
721 2 2261732 WASHER
725 1 2771601 ROPE ASSEMBLY
730 1 2281516 SPACER, INNER ARM
20 | minnkotamotors.com
©2015 Johnson Outdoors Marine Electronics, Inc.
PARTS LIST
