Table 1
TESTS ON PCB MIR080 WITH OXIMETER
Test
Procedure
Test method
Instrument
Expected result
Check battery pack application
there should be applied the double sided tape on the
battery pack
Visual
\
The doubled sided adhesives must be applied between
the PCB and the battery pack
Block of PCB on the lower case
There should be applied 11 screws and washers in the
special holes
Visual
\
The screws should be all correctly screwed
Display application on the upper case
There should be applied 6 nuts and showers between
display and case
Visual
\
The nuts should be all correctly screwed
White flat display application to the display
There should be applied and blocked with hot glue
Visual
\
Presence of hot glue on the connector
Brown flat display application
There should be applied a thick adhesive to the flat
Visual
\
Presence of a thick adhesive on the flat
Blocking of display flats
Application of thick adhesive on connectors J13 and
CONN1
Visual
\
Presence of a thick adhesive on the two connectors
Blocking of oximetry module
Check that the oximetry module has been correctly
applied
Visual
\
The doubled sided adhesives must be applied between
the PCB and the greatest micro on the oximetry module
