74
Configuration with the CFG-300 LCD Service Tool
Command Menu/Set Time
2. Set time and date
Default
00:00 MON 2000-01-01
Use this menu to set the
time and date. Use the left
and right arrow buttons to
move the cursor to the
desired location in the
display and use the up and
down arrow buttons to
increase or decrease the
values. Press ENTER to
accept the changes and
press CANCEL to ignore
the changes.
Note: time is in 24 hour
format
Command Menu/Set Time
2. Compensation
When value is entered the
following message appears
Compensation value
can range from -15 to
+15 seconds.
Use the up down arrow
buttons to select daily
compensation value and
press ENTER. For a fast
clock adjust negatively. For
a slow clock adjust
positively. For example: for
a clock which runs 5
minutes a month (based on
30 days) fast select -10
seconds.
HH:MM WKD YYYY-MM-DD
00:00 MON 2000-01-01
Daily Compensation:
Panel Config Updated
