MIDI THRU MIDI IN MIDI OUT SUSTAIN VOLUME AUX.OUT DC 12V USB
MIDI THRU MIDI IN MIDI OUT SUSTAIN VOLUME AUX.OUT DC 12V USB
Sustain Jack
Volume Jack
USB Jack
Connection
10
1. An optional footswitch can be plugged into the
[SUSTAIN] jack for sustain control.
2. The footswitch functions like the damper pedal on a
piano-press for sustain, release for normal sound.
1. Connect PC or other USB host devices that support
USB audio.
2. For devices with USB cable, after the driver is installed
and initialization is finished, you can choose USB audio
device in the device menu of the software to transfer
midi data.
An optional volume control can be plugged into the
[VOLUME] jack for adjusting the volume of sound.
