Using the phone system 33Final
Activating a 5224/5324 phone
To activate a Mitel phone you need (1) an extension number, (2) a phone, and
(3) a PIN. Your administrator can provide you with an extension number and
initial PIN.
To activate your phone, follow these steps:
1 Disconnect your computer from the network.
2 Plug the phone into the network.
3 Plug the computer into the phone at the port marked PC.
4 Connect one end of the phone power pack into your phone and the other
end into a power outlet.
Note: If your network is configured with Power Over Ethernet (POE), the
above step is not necessary.
5 Wait for the phone to display the following (this may take 30 seconds or
more):
6 Press the ACTIVATE softkey.
The display will show:
7 Enter your extension.
8 If you have login/logout privileges, the display will show:
Enter your PIN, then press the ENTER softkey.
9 If you do not have login/logout privileges, the display will show
:
Press the YES softkey.
10 The display will show
:
You have now successfully activated the phone, and can make calls.
Logged Out
ACTIVATE
Extension:
QUIT
PIN:
ENTER QUIT
Extension: 314
YES NO
Extension: 314
REDIAL CALLS MENU
