Table 13 Mounting Set for Fan Unit
Figure 25: Installing Slides
52/BYB 501 Mounting Set included in Fan Unit BFD 509 08/4
Pos. Title/Function Product Number Quantity
D SLIDE SXA 123 0320/1 2
E SPRING SXA 123 0321/1 2
F SCREW 24/SBF 228 040/0080 2
C SCREW M 6X16 03/SBA 121 060/0160 4
A CAPTIVE NUT M6 SBM 173 060/03 4
To Next Page
