Mitsubishi Electric MELSEC iQ-RJ71EIP91 - Identity

158
APPX
Appendix 4 Details of Message Communication Support Command
Identity
Class attribute (instance ID: 00H)
Class service
Instance attribute (instance ID: 01H)
■Details of product status
Object name Class ID
Identity 01H
Attribute
ID
Access
(: Available, :
Not available)
Name Data
type
Description Setting value
(Set)/stored
value (Get)
Get Set
1 Revision UINT Object revision 0001H
2 Max Instance UINT Maximum instance ID 0001H
3 Number of instances UINT Number of created instances 0001H
Service code Service Remarks
01H Get_Attributes_All 00H is stored in the fourth to seventh bytes.
0EH Get_Attribute_Single 
Attribute
ID
Access
(: Available, :
Not available)
Name Data
type
Description Setting value
(Set)/stored
value (Get)
Get Set
1 Vendor Id UINT Vendor ID number 00A1H
2 Device Type UINT Device type 000CH
3 Product Code UINT Product ID number 0008H
4 Revision Major Revision USINT Major revision 01H
Minor Revision USINT Minor revision 01H
5 Status WORD Product status Page 158
Details of
product status
6 Serial Number UDINT Serial number Varies between
modules.
7 Product Name STRING Product name "RJ71EIP91"
Bit Description Value
0 Owned • 0: EtherNet/IP communications are not connected as the target device.
• 1: At least one connection of EtherNet/IP communications is connected as the target device.
1 Reserved Fixed to 0
2 Configured Fixed to 1
3 Reserved Fixed to 0
4 to 7 Extended Device Status • 0010 (2H): Error occurring on one or more connections
• 0011 (3H): No connections established
• 0101 (5H): Major Recoverable Fault or Major Unrecoverable Fault occurring
• 0110 (6H): One or more connections performing normal communications in RUN mode
• 0111 (7H): One or more connections all performing communications in IDLE mode
8 Minor Recoverable Fault • 0: No error
• 1: Minor error occurring
9 Minor Unrecoverable Fault Fixed to 0
10 Major Recoverable Fault • 0: No error
• 1: Moderate error occurring
11 Major Unrecoverable Fault • 0: No error
• 1: Major error occurring
12 to 15 Extended Device Status 2 Fixed to 0
