2 - 27
2 SYSTEM CONFIGURATION
2.4.2 Power supply module
(1) Table of the power supply module specifications
This section describes the power supply modules specifications.
Item Q61P-A1 Q61P-A2 Q61P Q62P
Base loading position Q series power supply module loading slot
Applicable base unit Q38DB, Q312DB, Q63B, Q65B, Q68B, Q612B
Input power supply
100 to 120VAC
(+10%/-15%)
(85 to 132VAC)
200 to 240VAC
(+10%/-15%)
(170 to 264VAC)
100 to 240VAC (+10%/-15%)
(85 to 264VAC)
Input frequency 50/60Hz ±5%
Input voltage distortion factor 5% or less
Max. input apparent power 105VA 130VA 105VA
Inrush current 20A 8ms or less
(Note-4)
5VDC 6A 3A
Rated output current
24VDC —— 0.6A
External output voltage —— 24VDC±10%
5VDC 6.6A or more 3.3A or more Overcurrent
protection
(Note-1)
24VDC —— 0.66A or more
Overvoltage
protection
(Note-2)
5VDC 5.5 to 6.5V
Efficiency 70% or more 65% or more
Allowable momentary power failure
time
(Note-3)
20ms or less
Dielectric withstand voltage
Across inputs/LG and outputs/FG
2,830VAC rms / 3 cycles (Altitude : 2000m (6561.68ft.) )
Insulation resistance
Across inputs and outputs (LG and FG separated), across inputs and LG/FG, across outputs and
LG/FG 10M
or more by insulation resistance tester (500VDC)
Noise immunity
• By noise simulator of 1,500Vp-p noise voltage, 1
µ
s noise width and 25 to 60Hz noise frequency
• Noise voltage IEC61000-4-4, 2kV
Operation indication LED indication (Normal : ON (Green), Error : OFF)
Fuse Built-in (Unchangeable by user)
Application ERR contact
Rated switching
voltage/current
24VDC, 0.5A
Minimum switching load 5VDC, 1mA
Response time OFF to ON: 10ms or less. ON to OFF: 12ms or less.
Life time
Mechanical : 20 million times or more
Electrical : 100 thousand times at rated switching voltage/current or more
Surge suppressor None
Contact
output
section
Fuse None
Terminal screw size M3.5 screw
Applicable wire size 0.75 to 2mm
2
Applicable crimping terminal RAV1.25 to 3.5, RAV2 to 3.5
Applicable tightening torque 0.66 to 0.89 N•m
Exterior dimensions[mm(inch)]
98(H) × 55.2(W) × 90(D)
(3.86(H) × 2.17(W) × 3.54(D) )
Mass [kg] 0.31 0.40 0.39
