CHAPTER 2 SYSTEM CONFIGURATION
2
2.3 Precautions for System Configuration
2.3 Precautions for System Configuration
This section describes restrictions on the system configuration using the Q series CPU module.
(1) Number of mountable modules
The number of mountable modules and supported functions are restricted depending on the module type.
(a) When the Basic model QCPU is used
*1 The number is a total of the CC-Link IE Controller Network module and MELSECNET/H module.
*2 Modules of function version B or later are available.
*3 The number is for interrupt modules with no interrupt pointer setting.
With interrupt pointer setting, there is no restriction on the number of modules.
For interrupt pointer setting, refer to the following.
Qn(H)/QnPH/QnPRHCPU User's Manual (Function Explanation, Program Fundamentals)
*4 For the available GOT models, refer to the following.
GOT-A900 Series User's Manual (GT Works2 Version2/GT Designer2 Version2 Compatible Connection System
Manual)
GOT1000 Series Connection Manual (Mitsubishi Products) for GT Works3
GOT2000 Series Connection Manual (Mitsubishi Products) For GT Works3 Version1
*5 One module can be mounted for one control CPU.
*6 The module is available only when the interrupt module is selected by setting the function selector switch (SW2) to OFF.
Product Model
Maximum number of
modules/units per system
CC-Link IE Controller Network module
• QJ71GP21-SX
• QJ71GP21S-SX
Only 1 module
*1
MELSECNET/H module
• QJ71LP21
• QJ71BR11
• QJ71LP21-25
• QJ71LP21S-25
• QJ71LP21G
• QJ71LP21GE
• QJ71NT11B
Ethernet module
• QJ71E71
• QJ71E71-B2
• QJ71E71-B5
• QJ71E71-100
Only 1 module
CC-Link module
• QJ61BT11
• QJ61BT11N
Up to 2 modules
*2
Interrupt module
•QI60
*1
Only 1 module
*3
• QX40H
*6
• QX70H
*6
• QX80H
*6
• QX90H
*6
High speed data logger module • QD81DL96
Only 1 module
*5
High speed data communication module • QJ71DC96
Only 1 module
*5
GOT
• GOT-A900 Series (for bus
connection only)
*4
• GOT1000 Series (for bus
connection only)
*4
• GOT2000 Series (for bus
connection only)
*4
Up to 5 units
