CHAPTER 4 INSTALLATION AND WIRING
4
4.1 Installation Environment and Installation Position
4.1.1 Installation environment
CHAPTER 4 INSTALLATION AND WIRING
4.1 Installation Environment and Installation Position
4.1.1 Installation environment
Install the programmable controller according to the installation environment shown in the general specifications.
( Page 117, CHAPTER 5)
Do not install the programmable controller to the place where:
• An ambient temperature is outside the range of 0 to 55°C;
• Ambient humidity is outside the range of 5 to 95%RH,
• Condensation occurs due to rapid temperature change;
• Corrosive gas or combustible gas is present;
• Conductive powder such as dust and iron powder, oil mist, salinity, or organic solvent is filled;
• The programmable controller is exposed to direct sunlight;
• A strong electric field or strong magnetic field is generated; and
• The programmable controller is subject to vibration and shock.
