680
Appendix 13 External Dimensions
Appendix 13.1 CPU modules
(1) Q00JCPU
(2) Q00UJCPU
Unit: mm
Unit: mm
244.4
98
7
98
80±0.3
15.5
224.4±0.3
4-mounting screws (M4×14)
224.4±0.3
244.4
80±0.3
98
7
98
4
15.5
4-mounting screws (M4×14)
