Tire pressure monitoring system
5-120 Features and controls
N00532701334
When the ignition switch is turned to the
“ON” position or the operation mode is put in
ON, the tire pressure monitoring system
warning light normally illuminates and goes
off a few seconds later.
If one or more of the vehicle tires (except for
the spare tire) is significantly under-inflated,
the warning light will remain illuminated
while the ignition switch is in the “ON” posi-
tion or the operation mode is put in ON.
Refer to “If the warning light / display illumi-
nates while driving” on page 5-122 and take
the necessary measures.
The tire pressure monitoring system is not a
substitute for regularly checking tire infla-
tion pressures.
Be sure to check the tire inflation pressures
as described in “Tires” on page 9-15.
The tire inflation pressure sensor (A) is
installed in the illustrated location.
• On vehicles with Type 1 sensor which has
the metallic air valve (B), replace grommet
and washer (C) with a new one when the
tire is replaced.
• On vehicles with Type 2 sensor which has
the rubber air valve (D), replace rubber
valve (D) with new one when the tire is
replaced.
For details, please contact your authorized
Mitsubishi Motors dealer.
Tire pressure monitoring sys-
tem warning light / display
In addition, the warning display is displayed
on the information screen in the multi-infor-
mation display.
