Instrument cluster
Features and controls 5-127
5
N00519101272
The speedometer shows the vehicle speed in
miles per hour (mph) or kilometers per hour
(km/h).
N00519201303
The tachometer shows engine revolutions per
minute. This allows the driver to determine
the most efficient selector position and engine
speed combinations.
This gauge also assists in evaluating engine
performance.
N00554901248
Each time you press this button, there is a
sound and the brightness of the instruments
changes.
2- Multi Information display (Type
1:Color liquid crystal display type)
P.5-128
Information screen display list (Type 1)
P.5-155
Multi Information display (Type
2:Mono-color liquid crystal display
type) P.5-146
3- Speedometer P.5-127
4- Rheostat illumination button (Type 1)
P.5-127
5- Multi information display switch (Type
2) P.5-147
Speedometer
Type A
Tachometer
Type B
CAUTION
The red zone indicates an engine speed
beyond the range of safe operation.
Select the correct selector position to control
the engine speed so that the tachometer indi-
cator does not enter the red zone.
Meter illumination control
(Vehicle equipped with the
multi information display -
Type 1)
1- Brightness level
2- Rheostat illumination button
BK0223400US.book 127 ページ 2015年2月13日 金曜日 午後12時15分
