N00555801202
When the ignition switch is turned to the “ON” position or the operation mode is put in ON, the display screen switches in the following order.
1-
Trip odometer P.5-135
2-
Trip odometer P.5-135
3- ECO score display P.5-139
4- Service reminder P.5-136
5- Redisplay of a warning display screen P.5-134
Information screen (With the ignition switch is turned from the “OFF” or “LOCK” position to the
“ON” position or the operation mode is changed from OFF to ON)
*: When the inspection time has arrived
1- Screen when the ignition switch or the operation mode is OFF
2- System check screen P.5-137
3- Screen when the ignition switch or the operation mode is ON
4- Service reminder P.5-136
