Never exceed the vehicle capacity weight,
maximum trailer weight (A), maximum
tongue weight (B) and Gross Axle Weight
Rating (GAWR).
The vehicle capacity weight is printed on the
tire and loading information placard as “com-
bined weight of occupants and cargo”.
The weight includes the weight of all occu-
pants and the total weight it can carry.
For more information, refer to “Tire and load-
ing information placard” on page 6-7.
Recommendations for towing up to this limit
are as follows.
The tongue weight of any trailer is important
because it affects the vehicle capacity weight.
The vehicle capacity weight includes any
cargo you may carry, and the people who will
be riding in the vehicle. If you will tow a
trailer, you must include the tongue weight of
the trailer in your calculation of the vehicle
capacity weight. For more information
regarding vehicle capacity weight, refer to
“Tire and loading information placard” on
page 6-7.
Do not exceed the maximum tongue weight
for your vehicle.
After you’ve loaded your trailer, weigh the
trailer and then the tongue, separately, to see
if the weights are proper.
Keep the trailer tongue load at 10% of the
loaded trailer weight for dead weight hitches.
Weight limits
Vehicle capacity weight
Maximum trailer weight
Models Maximum trailer weight
2.4 liter models
With brake 1,500 lbs. (680
kg)
Without brake 1,250 lbs.
(567 kg)
3.0 liter models
With brake 3,500 lbs.
(1,588 kg)
Without brake 1,400 lbs.
(635 kg)
Tongue weight
Models Maximum tongue weight
2.4 liter models
With brake 150 lbs. (68
kg)
Without brake 125 lbs. (57
kg)
3.0 liter models
With brake 350 lbs. (159
kg)
Without brake 140 lbs. (64
kg)
