4. To install the bulb, perform the removal
steps in reverse.
N00900301142
N00901901132
1. When replacing the bulb on the right side
of the vehicle, remove the clip (A) hold-
ing down the washer tank spout and move
the spout toward the rear of the vehicle.
2. Turn the cap (B) counterclockwise to
remove it.
3. Turn the bulb (C) counterclockwise to
remove it and then while holding down
the tab (D), pull out the bulb (E).
4. To install the bulb, perform the removal
steps in reverse.
N00943201359
The alignment of the headlights should be
checked by an authorized Mitsubishi Motors
dealer or a repair facility of your choice.
N00915501197
1. When replacing the bulb on the left side
of the vehicle, move the relay box toward
the rear of the vehicle. (if so equipped)
(Refer to “Headlight (low beam, except
for vehicles equipped with LED head-
lights): Step 1” on page 9-32.
When installing the bulb, align the tab (D)
with the notch (E) of the socket.
Headlights (low beam, for vehi-
cles equipped with LED head-
lights)
The headlights uses an LED instead of the
bulb.
Check with an authorized Mitsubishi Motors
dealer or a repair facility of your choice
when the light needs to be repaired or
replaced.
Headlights (high beam)
*- Front of the vehicle
Headlight aim adjustment
Front side-marker lights
