1.4 SPECIFICATIONS
The UPS name plate displays the rated kVA as well as nominal voltages and currents. The
name plate is located on the interior side of the UPS front door.
TABLE 1.1 Power Specifications
Rated output
Power
Input voltage
1 ph 3 wire or 2 ph 3 wire
Output voltage
1 ph 3 wire or 2 ph 3 wire
6kVA / 4.2kW
8kVA / 5.6kW
10kVA / 7.0kW
12kVA / 8.4kW
240/120, 208/120
240/120, 208/120
240/120, 208/120
240/120, 208/120
240/120, 208/120
240/120, 208/120
240/120, 208/120
240/120, 208/120
TABLE 1.2 UPS Module Information
UPS
(kVA)
CABLE
ENTRY
WIDTH
(in/mm)
DEPTH
(in/mm)
HEIGHT
(in/mm)
WEIGHT*
(lb./kg)
HEAT LOSS
@ 208V
(kBTU/h)
6 REAR 13.8 / 350 29.9 / 760 27.8 / 705 307/140 2.2
8 REAR 13.8 / 350 29.9 / 760 40.6 / 1030 507/230 2.9
10 REAR 13.8 / 350 29.9 / 760 40.6 / 1030 507/230 3.6
12 REAR 13.8 / 350 29.9 / 760 40.6 / 1030 507/230 4.3
* Including batteries
TABLE 1.3 Rating of Contactors and Fuses
Component(s) Description Component Rating @ 208V,3 phase, 60 Hz
UPS Rating 6 kVA 8 kVA 10 kVA 12 kVA
CB1 AC Input Contactor 80A 80A 80A 80A
CB2 DC Input Contactor 32A 60A 60A 60A
FCR, FCS AC Input Fuse 80A/240V 80A/240V 80A/240V 80A/240V
FIU, FIV Inverter Output Fuse 80A/240V 80A/240V 80A/240V 80A/240V
FUBU, FUBV 30A/600V 30A/600V 30A/600V 30A/600V
FD1, FD3 UMAR-A 40A/660V 80A/660V 80A/660V 80A/660V
FD2 UMAR-A 80A/500Vdc 80A/500Vdc 80A/500Vdc 80A/500Vdc
