TABLE 1.4 Detail of Specifications
Rated Output kVA 6 8 10 12
Rated Output kW 4.2 5.6 7.0 8.4
AC INPUT CHARACTERISTICS
Configuration 1 phase 3 wire or 2 phase 3 wire
Voltage 240/120V (1 phase), 208/120V (2 phase)
Frequency 50 / 60 Hz +/-5%
Reflected Current THD 4% typ. at 100% load; 7% typ. at 50% load
BATTERY
Type VRLA
Ride Through 10min. at 100%
load
15min. at 100%
load
12min. at 100%
load
10min. at 100%
load
Nominal Voltage 216 Vdc
Minimum Voltage 173 Vdc
Number of Cells 108
AC OUTPUT
Configuration 1 phase 3 wire or 2 phase 3 wire
Voltage 240/120V (1 phase), 208/120V (2 phase)
Voltage Stability +/-2% steady state
Frequency 50 / 60 Hz
Frequency Stability +/-0.01% in free running mode
Power Factor 0.7 nominal
Power Factor range 0.7 ~ 1.0 lagging (within output kW rating)
Voltage THD 2% typical THD at 100% Linear Load
5% typical THD at 100% non-linear load
Transient Response +/-3% typical at 100% load step
+/-1% typical at loss/return of AC power
+/-3% typical at load transfer to/from static bypass
Transient Recovery 50 ms
Voltage Unbalance 2% typical at 100% unbalanced load
Phase Displacement 1deg. typical at 100% load
Inverter Overload 150% for 1 minute
System Overload 150% for 1 minute, 1000% for 1 cycle (with bypass available)
Bypass Overload 150% for 1 minute, 1000% for 1 cycle
Crest Factor Capabilities 3:1
ENVIRONMENTAL
Cooling Forced Air
Operating Temperature 32°F ~ 104°F (0°C ~ 40°C). Recommended 59°F ~ 77°F (15°C ~ 25°C)
Relative Humidity 5% ~ 95% Non Condensing
Altitude 0 ~ 9000 feet No Derating
Location Temperature-controlled, indoor area free of conductive contaminants
