Mitsubishi FX2N series User Manual

FX2N Series Programmable Controllers Standards
x
Models : MELSEC FX
0N
series manufactured
from
November 1st, 1995 FX
0N
-8EX-ES, FX
0N
-8EYR-ES, FX
0N
-8EYT-ESS
from
February 1st, 1996 FX
0N
-8ER-ES, FX
0N
-16EX-ES, FX
0N
-16EYR-ES,
FX
0N
-16EYT-ESS
from
April 1st, 1996 FX
0N
-8ER-ES/UL, FX
0N
-16EX-ES/UL, FX
0N
-16EYR-ES/UL,
FX
0N
-16EYT-ESS/UL
from
May 1st, 1996 FX
0N
-232ADP
FX
0N
-485ADP
from
July 1st, 1996 Harmonized Products
FX
0N
-8EX-ES/UL, FX
0N
-8EYR-ES/UL, FX
0N
-8EYT-ESS/UL
Models : MELSEC FX
2NC
series manufactured
from October 1st, 2002
FX
2NC
-232ADP
FX
2NC
-485ADP
Models : MELSEC FX series manufactured
from
August 1st, 1995 FX-EPROM-8, FX-EEPROM-8, FX-EEPROM-4,
FX-RAM-8
from
July 1st, 1997 FX-EEPROM-16
to March 31st, 2002 [compliance with EN50081-2 (EN61000-6-4) and prEN50082-2]
from April 1st 2002:Above mentioned products [compliance with EN50081-2 (EN61000-6-4) and EN61131-2]
Standard Remark
EN50081-2:1993 Electromagnetic compatibility
EN61000-6-4:2001 - Generic emission standard
Industrial environment
Compliance with all relevant aspects of the standard.
(Radiated Emissions and Mains Terminal Voltage Emissions)
EN61000-6-2:2001 Electromagnetic compatibility
- Generic immunity standard
Industrial environment
Compliance with all relevant aspects of the standard.
(RF immunity, Fast Transients, ESD, Conducted, Surge,
Power magnetic fields, Voltage dips and Voltage interruptions)
Standard Remark
EN50081-2:1994 Electromagnetic compatibility
EN61000-6-4:2001 - Generic emission standard
Industrial environment
Compliance with all relevant aspects of the standard.
(Radiated Emissions and Mains Terminal Voltage Emissions)
EN50082-2:1992 Electromagnetic compatibility
- Generic immunity standard
Industrial environment
Compliance with all relevant aspects of the standard.
(RF immunity, Burst Transients and ESD)
EN61131-2:1994 Programmable controllers
/A11:1996 - Equipment requirements and tests
/A12:2000
Compliance with all relevant aspects of the standard.
(RF Immunity, Fast Transients, ESD and Damped oscillatory
wave)

Mitsubishi FX2N series Specifications

General

Type	Programmable Logic Controller (PLC)
Manufacturer	Mitsubishi Electric
Series	FX2N
Power Supply	100-240VAC or 24VDC
Program Capacity	8, 000 steps
Expansion	Yes, via expansion modules
Operating Temperature	0 to 55°C
I/O Points	16 to 256 points
Communication	RS-422, RS-485
Programming Language	Ladder Logic
Instruction Execution Speed	0.08 µs/basic instruction
Mounting	DIN rail
Data Memory	8, 000 words
Expansion Modules	Analog, digital, communication
Humidity	5 to 95% RH (non-condensing)
