Mitsubishi FX2N series User Manual

FX2N Series Programmable Controllers Standards
xi
LV D
The following products have shown compliance through direct testing (of the identified standards below) and design
analysis (through the creation of a technical construction file) to the European Directive for Low Voltage (73/23/EEC) when
used as directed by the appropriate documentation.
Refer to a manual or related material of each product other than the following.
Type : Programmable Controller (Open Type Equipment)
Models : MELSEC FX
2N
series manufactured
from July 1st, 1997 FX
2N
-

MR-ES/UL FX
2N
-

MT-ESS/UL
Where

indicates:16,32,48,64,80,128
FX
2N
-
ËË
ER-ES/UL FX
2N
-
ËË
ET-ESS/UL
Where
ËË
indicates:32,48
FX
2N
-16EYR-ES/UL
from April 1st, 1998 FX
2N
-

MR-DS
Where

indicates:32,48,64,80
FX
2N
-48ER-DS
from August 1st, 1998 FX
2N
-
UU
MR-UA1/UL
Where
UU
indicates:16,32,48,64
FX
2N
-16MR-DS FX
2N
-48ER-UA1/UL
from August 1st, 2005 FX
2N
-8ER-ES/UL FX
2N
-8EYR-ES/UL
For the products above, PLCs manufactured
before March 31st, 2002 are compliant with IEC1010-1
from April 1st, 2002 to April 30th, 2006 are compliant with EN61131-2:1994+A11:1996+A12:2000
after May 1st, 2006 are compliant with EN61131-2:2003
Models : MELSEC FX
0N
series manufactured
from November 1st, 1995 FX
0N
-8EX-ES, FX
0N
-8EYR-ES, FX
0N
-8EYT-ESS
from February 1st, 1996 FX
0N
-8ER-ES, FX
0N
-16EX-ES, FX
0N
-16EYR-ES, FX
0N
-16EYT-ESS
from April 1st, 1996 FX
0N
-8ER-ES/UL, FX
0N
-16EX-ES/UL, FX
0N
-16EYR-ES/UL,
FX
0N
-16EYT-ESS/UL
from July 1st, 1996 Harmonized Products
FX
0N
-8EX-ES/UL,
FX
0N
-8EYR-ES/UL, FX
0N
-8EYT-ESS/UL
* Compliance to BSEN61010-1 and Amendment2 is claimed through virtue of direct compliance to IEC1010-1,
Amendment 1 and Amendment 2.
Standard Remark
IEC1010-1:1990 Safety requirements for electrical
/A1:1992 equipment for measurement, control,
and laboratory use
- General requirements
The equipment has been assessed as a component for fitting
in a suitable enclosure which meets the requirements of
IEC 1010-1:1990+A1:1992
EN61131-2:1994 Programmable controllers
/A11:1996 - Equipment requirements and tests
/A12:2000
The equipment has been assessed as a component for fitting
in a suitable enclosure which meets the requirements of
EN61131-2:1994+A11:1996+A12:2000
EN61131-2:2003 Programmable controllers
- Equipment requirements and tests
The equipment has been assessed as a component for fitting
in a suitable enclosure which meets the requirements of
EN61131-2:2003
Standard Remark
IEC1010-1:1990 Safety requirements for electrical
/A1:1992 equipment for measurement, control,
/A2:1995 and laboratory use
BSEN61010-1 :1993 *
/A2:1995
The equipment has been assessed as a component for
fitting in a suitable enclosure which meets the
requirements of IEC 1010-1:1990,A1:1992 and
A2:1995(BSEN61010-1 :1993 and A2:1995)

Mitsubishi FX2N series Specifications

General

Type	Programmable Logic Controller (PLC)
Manufacturer	Mitsubishi Electric
Series	FX2N
Power Supply	100-240VAC or 24VDC
Program Capacity	8, 000 steps
Expansion	Yes, via expansion modules
Operating Temperature	0 to 55°C
I/O Points	16 to 256 points
Communication	RS-422, RS-485
Programming Language	Ladder Logic
Instruction Execution Speed	0.08 µs/basic instruction
Mounting	DIN rail
Data Memory	8, 000 words
Expansion Modules	Analog, digital, communication
Humidity	5 to 95% RH (non-condensing)
