Mitsubishi FX2N series User Manual

FX2N Series Programmable Controllers Introduction 1
1-4
*1 This value is current consumption of FX2N-
422-BD only. The user must consider the
current draw of other equipment cnnected via
the board.
Please see the appropriate manual for current
consumption values.
*2 The communication adapter needs to connect
via FX
2N
-CNV-BD to FX
2N
Series PLC.
*1 Dies ist nur die Stromaufnahme des FX2N-
422-BD. Berücksichtigen Sie auch die
Stromaufnahme der angeschlossenen
Geräte.
Nähere Hinweise zur Stromaufnahme finden
Sie in den Handbüchern zu diesen Geräten.
*2 Das Modul wird über einen Kommunikations-
adapter FX
2N
-CNV-BD mit dem FX
2N
-
Grundgerät verbunden.
*1 Esto es sólo la alimentación de corriente del
FX2N-422-BD. Considere también la
alimentación de corriente de los aparatos
conectados. Mayores informaciones acerca
de la alimentación de corriente pueden
encontrarse en los manuales de estos
aparatos.
*2 El módulo es conectado a través del
adaptador de comunicación FX2N-CNV-BD
con el aparato base FX2N
*1 Représente seulement la consommation du
FX2N-422-BD. Prenez également en
considération la consommation des appareils
raccordés. Vous trouverez de plus amples
informations sur la consommation dans les
manuels de ces appareils.
*2 Le module est raccordé à l'appareil de base
FX2N via un adaptateur de communication
FX2N-CNV-BD.
*1 Si tratta solo dell'assorbimento di corrente
della serie FX2N-422-BD. Si prega di
prendere in considerazione anche
l'assorbimento di corrente degli strumenti
collegati. Ulteriori informazioni riguardanti
l'assorbimento di corrente sono reperibili nei
manuali degli strumenti.
*2 Il modulo è collegato allo strumento base
FX2N mediante adattatore di comunicazione
FX2N-CNV-BD.
Table 1.5: ENG
☞
Expansion board and communication adapter
FRE
☞
Adaptateur d'interface, adaptateur d'allocation de valeur de consigne analogique et modules de
communication
GER
☞
Schnittstellenadapter, analoger Sollwertvorgabe-Adapter und Kommunikationsmodule
ITL
☞
Adattatore di interfaccia, adattatore analogico dei valori reali programmati e moduli di comunicazione
ESP
☞
Adaptador de interfaz, adaptador análogo de indicación de valor nominal y módulos de comunicación
MODEL DESCRIPTION
NUMBER Current Consumed
DEIMENSIONS
mm (inch)
MASS (WEIGHT)
kg (lbs)
I O
Internal
5V DC
External
24V DC
FX
2N
-232-BD RS-232C communication interface - 0 - 20mA -
Mounts directly into
top of PLC
Mounts directly
into top of PLC
FX
2N
-422-BD RS-422 communication interface - 0 -
60mA
*1
-
FX
2N
-485-BD RS-485 communication interface - 0 - 60mA -
FX
2N
-CNV-BD
Communication adapter
connection interface
-0- - -
FX
2N
-8AV-BD Analog potentiometer - 0 - 20mA -
FX
2NC
-232ADP
*2
RS-232C communication adapter - 0 - 100mA -
19.1
(0.76)
90
(3.55)
85
(3.35)
0.1 (0.22)
FX
0N
-232ADP
*2
RS-232C communication adapter - 0 - 200mA -
43
(1.70)
68
(2.68)
FX
2NC
-485ADP
*2
RS-485 communication adapter - 0 - 150mA -
19.1
(0.76)
78
(3.08)
FX
0N
-485ADP
*2
RS-485 communication adapter - 0 - 30mA 50mA
43
(1.70)
87
(3.43)
0.3 (0.66)
ENG
GER
ESP
FRE
ITL

Mitsubishi FX2N series Specifications

General

Type	Programmable Logic Controller (PLC)
Manufacturer	Mitsubishi Electric
Series	FX2N
Power Supply	100-240VAC or 24VDC
Program Capacity	8, 000 steps
Expansion	Yes, via expansion modules
Operating Temperature	0 to 55°C
I/O Points	16 to 256 points
Communication	RS-422, RS-485
Programming Language	Ladder Logic
Instruction Execution Speed	0.08 µs/basic instruction
Mounting	DIN rail
Data Memory	8, 000 words
Expansion Modules	Analog, digital, communication
Humidity	5 to 95% RH (non-condensing)
