FX2N Series Programmable Controllers Introduction 1
1-5
1
2
3
4
5
6
7
A
B
C
Table 1.6: ENG
Special function blocks FRE
Modules spéciaux
GER
Sondermodule ITL
Moduli speciali
ESP
Módulos especiales blocks
MODEL DESCRIPTION
NUMBER
OF I/O
Current Consumed
DIMENSIONS
mm
(inches)
MASS
(WEIGHT)
kg (lbs)
I O
Internal
5V DC
External
24V DC
FX
0N
-3A Analog/Digital converter - 8 - 30mA
90mA
*1
43
(1.70)
90
(3.55)
87
(3.43)
0.20 (0.44)FX
2N
-2AD Analog to digital converter - 8 - 20mA
50mA
*1
FX
2N
-2DA Digital to analog converter - 8 - 30mA
85mA
*1
FX
2N
-4DA Digital to analog converter - 8 - 30mA 200mA
55
(2.17)
0.30 (0.66)
FX
2N
-4AD Analog to digital converter - 8 - 30mA 55mA
FX
2N
-5A Analog/Digital converter - 8 - 70mA 90mA
FX
2N
-8AD Analog to digital converter - 8 - 50mA 80mA
75
(2.96)
FX
2N
-4AD-PT PT100 probe interface - 8 - 30mA 50mA
55
(2.17)
FX
2N
-4AD-TC Thermo-couple interface - 8 - 30mA 50mA
FX
2N
-2LC Temperature Control Block - 8 - 70mA 55mA
FX
2N
-1HC High speed counter - 8 - 90mA NA
55
(2.17)
90
(3.55)
87
(3.43)
0.30 (0.66)
FX
2N
-1PG-E Pulse output, Position control - 8 - 55mA 40mA
43
(1.70)
0.20 (0.44)
FX
2N
-10PG Pulse output, Position control - 8 - 120mA
*2
FX
2N
-10GM Positioning Controller (1 axis) - 8 -
NA NA
60
(2.37)
0.30 (0.66)
FX
2N
-20GM Positioning Controller (2 axis) - 8 -
86
(3.39)
0.40 (0.88)
FX
2N
-1RM-E-
SET
Programmable Cam Switch - 8 - NA 250mA
55
(2.17)
111
(4.38)
97
(3.82)
0.50 (1.10)
FX
2N
-232IF RS232 Interface block - 8 - 40mA 80mA
90
(3.55)
87
(3.43)
0.30 (0.66)
FX
2N
-32CCL CC-Link Slave Interface - 8 - 130mA 50mA
43
(1.70)
0.20 (0.44)
FX
2N
-16CCL-M
*3
CC-Link Master module
*4
8
*4
NA 150mA
85
(3.35)
0.40 (0.88)
FX
2N
-64CL-M CC-Link/LT Interface block
*6
190mA
25mA
*7
43
(1.70)
0.30 (0.66)
FX
2N
-16LNK-M I/O Link Remote Master module
*5
200mA 90mA 0.30 (0.66)
FX
2N
-32ASI-M
*3
ASI Master Module
*8
8
*8
150mA
*9
55
(2.17)
0.20 (0.44)
FX
0N
-16NT Net-mini interface 8 8 20mA 60mA
43
(1.70)
