Features and controls

3-283

USB input terminal

(if so equipped)

N00566700015

You can connect your USB memory device or iPod* to play

music files stored in the USB memory device or iPod.

The following explains how to connect and remove a USB

memory device or iPod.

Refer to the following sections for details on how to play music

files:

Refer to “To play tracks from USB device” on page 5-111.

*: “iPod” is a registered trademark of Apple Inc. in the United

States and other countries.

How to connect a USB memory device

N00566800074

1. Park your vehicle in a safe place and turn the ignition

switch to the “LOCK” position.

2. Open the USB input terminal cover (A) in the glove com-

partment.
