Overview

Interior

N00100301173

Adjustable seat belt shoulder

anchor (for front seats) P.2-19

Seat belts P.2-13

Supplemental restraint system - side airbag

(for front seats, if so equipped) P.2-51

Front seats P.2-3

Sun visors P.3-288

Vanity mirror P.3-288

Inside rearview mirror

P.3-80, 3-176

Head restraints P.2-9

Window lock switch P.3-73

Power window

switches P.3-69

Power door lock

switch P.3-55

Electric remote-

controlled out-

side mirror switch

P.3 -8 3

Dome light (Front)/Reading lights

(if so equipped) P.3-292, 7-58, 7-85

Sunroof switch

(if so equipped)

P.3- 74

Bluetooth

2.0 interface microphone (if so equipped)

P.3 -2 56

Bottle holder (for front seat) P.3-303

BK0138600US.book 6 ページ２０１１年７月１７日　日曜日　午後２時３２分
