7-24
Vehicle care and maintenance
7
2. Turn the plastic nuts (C) counterclockwise, and then
remove the battery upper cover (D).
OTE
● Be careful not to lose the removed plastic nuts.
To instal l
1. Install the battery upper cover (A) onto the battery, and
then push the plastic nuts (B) in the direction shown by
the arrows to secure the cover.
OTE
● Be sure to install the plastic nuts in the correct direction.
● Make sure that the battery upper cover is installed
securely.
2. To install the air duct, perform the removal steps in
reverse.
