6.
HiQW
TO
USE
EACH
FUNCTION
MEU#CbA
i
I
[Explanation]
(1)
Turn
ON
a
device
number
set
by
pressing the [SHIFT]
+
[SET]
+'
[GO]
7
(111
+
POI) keys.
Turn
It
OFF
by pressing the
[SHIFT]
+
[RST]
+
[GO] ([O]
+
[GO]) keys.
r
!
I
(2)
When a device that is not displayed is set or reset, the corresponding
device and device state are displayed.
(3)
As for forcible setlreset operations when the ACPU is
in
the RUN state,
program execution has priority.
Therefore, even
if
forcible setheset is executed when an instruction using
a correspondent device is being executed, the state only changes for a
moment
and
returns back.
(4)
Even
if
a
process
input is OFF, when input
(X)
is
set
forcibly, an ACPU
executes
the
operation processing as ON.
And, even if input
(X)
is reset forcibly when a process input is ON, the
PC CPU is processed as ON.
If
input
(X)
was
set, be sure
to
reset it after the test operation has been
completed.
(5)
As
for special-function modules, some of the
Y
numbers cannot be
sethset.
(6)
Special relay
(M)
is controlled by the
OS
of
the CPU. Operate setheset
of special relays after checking the contents utilizing the User's Manual
of the connected ACPU.
(7)
Pressing the [SHIFT] and [TEST] keys in
,fhe
MONITOR mode (list
monitoring) enables the
test
operation of the designated device indicated
by the cursor
(
b
).
When the [SHIFT] and
[TEST]
keys are pressed in the READ, WRITE,
INSERT, DELETE, or MONITOR (list monitoring) mode, the test opera-
tion is enabled by inputting the designated device and device number.
IMPORTANT
I
I
Be
sure
to
reset devices set by this operation before operating.
Batch reset can
be
executed by using the CPU's
reset
switch.
L
?
I
i
I
'ii
i
F
i
I*
i
I
c
I
I
!
6-52
