Mitsubishi MELSEC QCPU User Manual

5 - 26 5 - 26
MELSEC-Q/QnA
5 SEQUENCE INSTRUCTIONS
High Performance
QnA Q4AR
Basic
QCPU
PLC CPU
Process CPU
5.3.4 Annunciator output (OUT F)
Usable Devices
Internal Devices
(System, User)
MELSECNET/10(H)
Direct J
\
Set
Data
Bit Word
File
Register
Bit Word
Special
Function
Module
U
\G
Index
Register
Zn
Constant
K, H
Other
D
(Only F)
[Instruction Symbol] [Execution Condition]
F35
Annunciator Number
OUT F
[Set Data]
Set Data Meaning Data Type
D
Number of annunciator to be turned ON Bit
[Functions]
(1) Operation results up to the OUT instruction are output to the designated annunciator.
(2) The following responses occur when an annunciator (F) is turned ON.
[With Q3A, Q4A, or Q4ARCPU]
• The annunciator number is displayed at the LED display device on the front of the CPU
module, and the "USER" LED goes ON.
• The annunciator numbers which are ON (F numbers) are stored in special registers (SD64 to
SD79).
• The value of SD63 is incremented by 1.
[With CPUs other than above]
• The "USER" LED goes ON.
• The annunciator numbers which are ON (F numbers) are stored in special registers (SD64 to
SD79).
• The value of SD63 is incremented by 1.
(3) If the value of SD63 is 16 (which happens when 16 annunciators are already ON), even if a
new annunciator is turned ON, its number will not be stored at SD64 to SD79.
