Mitsubishi PLK-E1008H User Manual

3 PLK-E1008H I/O TABLE
INPUT OUTPUT
TERMINAL SIGNAL
FUNCTION
TERMINAL SIGNAL CUSTOMIZE FUNCTION SOL No.
CON I-2 I1 START COND-1 O1 OT2 LOWER TRIMMER 8
CON I-3 I2 CLAMP COND-9 O2 OT1 WIPER 6
CON H-3 I4 STOP COND-2 O3 NO TENSION RELEASE 7
TE1-A2 I5 THICKNESS DETECTOR UP COND-10 O4 OF1 CLAMP LEFT 2
TE1-A4 I6 UPPER TRIMMER ACT COND-3 O5 OTA PRESSER FOOT 9
TE1-A6 I7 UPPER TRIMMER BACK TE2-A4 O6
OT4
HEATER -
TE1-A8 I8 UPPER THREAD PULL ACT TE2-A5 O7 OT5 THICKNESS DETECTOR 1
TE1-A10 I9 WIPER BACK TE2-A6 O8 OF2 CLAMP RIGHT 3
TE1-B4 IA WIPER ACT TE2-A7 O9 OT7 UPPER TRIMMER 4
TE1-B6 IB TENSION RELEASE BACK TE2-A8 OA OT8 THREAD PULLER 5
TE1-B8 IC TENSION RELEASE ACT TE2-A9 OB DRT NEEDLE COOLER 10
TE1-B10 ID PRESSER FOOT DOWN CONG-13 OH OTB BUZZER
TE2-A1 IE PRESSER FOOT UP
TE2-A3 IF LOWER TRIMMER ACT
TE2-B1 IG LOWER TRIMMER BACK
TE2-B3 IH NORMAL/TEST SWITCH
CON G-3 II LOWER TRIMMER SWITCH
CON G-4 IJ UPPER TRIMMER SWITCH

Mitsubishi PLK-E1008H Specifications

General

Brand	Mitsubishi
Model	PLK-E1008H
Category	Sewing Machine
Language	English
