5 PARAMETER SETTINGS
(2) Parameter settings for remote I/O station
Network parameter settings
(1) Ethernet
(2) CC-Link
Writing parameters to remote I/O module
Not
required
Required
To cable connection
PLC Parameters
(1) PLC system settings
(2) PLC RAS settings
(3) Operational settings
(4) I/O assignment
Set the following
functions as necessary.
Required
Not required
Intelligent function module parameter settings
Resetting network module
· · · ·
Section 5.1.1
1
1
2
Set the following
functions as necessary.
· · · ·
Section 5.2.1
· · · ·
Section 4.6
POINT
1) If no parameters are written to the remote I/O station, operation is performed
using the default settings. (See Section 5.2.1)
2) If the CPU module for the remote master station is reset or if set from STOP to
RUN, it also resets the remote I/O station.
However, the remote I/O station can be reset when the following conditions are
satisfied:
• When the PLC parameter/network parameter or remote password of a
remote I/O station is corrected and the corrected parameter is not effective
because the remote I/O station has been reset or due to other reasons.
• When a stop error has occurred. (Refer to section 8.3.2.)
3) Even if only one of the following settings is corrected, all the parameters are
written to the remote I/O module: PLC parameters, intelligent function module
parameters, network parameters, and remote password
1: The following settings can be performed for the I/O assignment.
1) Input module for I/O response time.
2) Output module error time output mode.
3) I/O assignment
4) Setting switches for intelligent function module.
2: Refer to the intelligent function module user's manual for details about
intelligent function module parameters.
5
