Mitsubishi RV-3S-S11 - 3.3.2 Installation dimensions

3-41 Outside dimensions/Installation dimensions
3 Controller
3.3.2 Installation dimensions
Fig.3-4 ： Installation of controller
50mm
SVO OFF
STOP
END
SVO ON
MODE
TEACH
AUTO
(Ext.)
AUTO
(Op.)
START
RESET
DOWN
UP
STATUS NUMBER
REMOVE T/B
EMG.STOP
CHANG DISP
50mm
170mm or more
